G45-1500

G45-1500

Horsepower: 750 - 1500

Displacement: 2.0L - 8.0L

Features:

  • G45-1500 compressor aero increases flow up to 18% (compared to GTX4508R 76mm)
  • 76mm compressor inducer | 109mm compressor exducer
  • Dual ceramic ball bearing with steel cages
  • G Series turbine aero increases flow 14% (compared to GTX45R)
  • Inconel turbine wheel with 89mm inducer flows up to 56 lbs/min
  • Lightweight aluminum backplate
  • Fully machined speed sensor and pressure ports
  • Stainless steel turbine housings available in T4 divided inlet

Flange diagram

Super Core

Compressor    Turbine
Super Core PN Inducer Exducer Trim A/R Inducer Exducer Trim Rotation Hinta
888169-5005S
Loppu varastosta
76mm 109mm 44 0.85 89mm 82mm 84 Standard
2469.00 € 1991.13 € alv. 0%
Compressor    Turbine
Super Core PN Inducer Exducer Trim A/R Inducer Exducer Trim Hinta
Turbo PN: 888169-5005S
2469.00 € 1991.13 € alv. 0%
888169-5005S
Compressor Inducer
76mm 		Exducer
109mm		 Trim
44		 A/R
0.85		 Turbine Inducer
89mm 		Exducer
82mm		 Trim
84
2469.00 €
Rotation: Standard Loppu varastosta | 1991.13 € alv. 0%

Turbine Hsg

Non Wastegate
Turbine Kit PN A/R Inlet Outlet Wastegate Divided Trim Rotation Hinta
757707-0024
Loppu varastosta
1.15 T4 V-Band No Yes 84 Standard
969.00 € 781.45 € alv. 0%
757707-0026
Loppu varastosta
1.44 T4 V-Band No Yes 84 Standard
1049.00 € 845.97 € alv. 0%
757707-0023
Loppu varastosta
1.01 T4 V-Band No Yes 84 Standard
969.00 € 781.45 € alv. 0%
757707-0025
Loppu varastosta
1.28 T4 V-Band No Yes 84 Standard
1019.00 € 821.77 € alv. 0%
757707-0021
Loppu varastosta
819.00 € 660.48 € alv. 0%
757707-0022
Loppu varastosta
849.00 € 684.68 € alv. 0%
757707-0019
Loppu varastosta
799.00 € 644.35 € alv. 0%
757707-0020
Loppu varastosta
799.00 € 644.35 € alv. 0%
Turbine Kit PN A/R Inlet Outlet Wastegate Divided Trim Hinta
Turbine Kit PN: 757707-0024
969.00 € 781.45 € alv. 0%
757707-0024
A/R
1.15		 Inlet
T4		 Outlet
V-Band		 Wastegate
No		 Divided
Yes		 Trim
84
969.00 €
Rotation: Standard Loppu varastosta | 781.45 € alv. 0%
Turbine Kit PN: 757707-0026
1049.00 € 845.97 € alv. 0%
757707-0026
A/R
1.44		 Inlet
T4		 Outlet
V-Band		 Wastegate
No		 Divided
Yes		 Trim
84
1049.00 €
Rotation: Standard Loppu varastosta | 845.97 € alv. 0%
Turbine Kit PN: 757707-0023
969.00 € 781.45 € alv. 0%
757707-0023
A/R
1.01		 Inlet
T4		 Outlet
V-Band		 Wastegate
No		 Divided
Yes		 Trim
84
969.00 €
Rotation: Standard Loppu varastosta | 781.45 € alv. 0%
Turbine Kit PN: 757707-0025
1019.00 € 821.77 € alv. 0%
757707-0025
A/R
1.28		 Inlet
T4		 Outlet
V-Band		 Wastegate
No		 Divided
Yes		 Trim
84
1019.00 €
Rotation: Standard Loppu varastosta | 821.77 € alv. 0%
Turbine Kit PN: 757707-0021
819.00 € 660.48 € alv. 0%
757707-0021
A/R
 Inlet
 Outlet
 Wastegate
 Divided
 Trim
819.00 €
Rotation: Loppu varastosta | 660.48 € alv. 0%
Turbine Kit PN: 757707-0022
849.00 € 684.68 € alv. 0%
757707-0022
A/R
 Inlet
 Outlet
 Wastegate
 Divided
 Trim
849.00 €
Rotation: Loppu varastosta | 684.68 € alv. 0%
Turbine Kit PN: 757707-0019
799.00 € 644.35 € alv. 0%
757707-0019
A/R
 Inlet
 Outlet
 Wastegate
 Divided
 Trim
799.00 €
Rotation: Loppu varastosta | 644.35 € alv. 0%
Turbine Kit PN: 757707-0020
799.00 € 644.35 € alv. 0%
757707-0020
A/R
 Inlet
 Outlet
 Wastegate
 Divided
 Trim
799.00 €
Rotation: Loppu varastosta | 644.35 € alv. 0%
