GBC22-350

Horsepower: 200 - 350

Displacement: 1.0L - 2.5L

Features:

44mm compressor inducer
Outline interchangeable with GBC 17 / 20
200-350 horsepower capability
Integrated wastegate assembly with calibrated actuator
Billet compressor wheel with extended tip design for higher pressure ratio capability
GTX Gen II compressor aero with modern gasoline turbine wheel aero
Supports up to 350 horsepower
Forged Fully-Machined Compressor Wheel
Journal Bearing Rotating Group
Internally wastegated turbine housing
Engineered for small displacement engines including powersports, personal watercraft and automobiles

	Compressor				Turbine			Turbine kit
Turbo PN	Inducer	Exducer	Trim	A/R	Inducer	Exducer	Trim	A/R	Inlet	Outlet	Wastegate	Divided	Rotation	Hinta
896055-5003S Loppu varastosta	44mm	56mm	62	0.59	50mm	46mm	84	0.64	T25	5-Bolt	Yes	No	Standard	870.00 € 701.61 € alv. 0%	Valitse

	Compressor				Turbine			Turbine kit
Turbo PN	Inducer	Exducer	Trim	A/R	Inducer	Exducer	Trim	A/R	Inlet	Outlet	Wastegate	Divided	Hinta
Turbo PN: 896055-5003S 870.00 € 701.61 € alv. 0%
896055-5003S	Compressor Inducer 44mm	Exducer 56mm	Trim 62	A/R 0.59	Turbine Inducer 50mm	Exducer 46mm	Trim 84	Turbine kit A/R 0.64	Inlet T25	Outlet 5-Bolt	Wastegate Yes	Divided No	870.00 €	Valitse
Rotation: Standard Loppu varastosta \| 701.61 € alv. 0%
