G30-660

G30-660

Horsepower: 350 - 660

Displacement: 1.4L - 3.0L

Features:

  • Garrett G Series compressor aerodynamics for maximum HP
  • New turbine wheel aero contructed of MAR-M alloy rated for up to 1050° C
  • Stainless steel turbine housing options rated for up to 1050° C
  • Oil restrictor and water fittings included
  • Fully machined speed senson and pressure ports

Turbocharger

Compressor    Turbine   Turbine kit
Turbo PN Inducer Exducer Trim A/R Inducer Exducer Trim A/R Inlet Outlet Wastegate Divided Rotation Hinta
880704-5002S Turbo G30-660 - 880704-5002S
Loppu varastosta
54mm 67mm 65 0.70 60mm 55mm 84 0.83 V-Band V-Band Yes No Standard
2039.00 € 1644.35 € alv. 0%
880697-5003S Turbo G30-660 - 880697-5003S
Loppu varastosta
54mm 67mm 65 0.70 60mm 55mm 84 1.01 V-Band V-Band No No Standard
1909.00 € 1539.52 € alv. 0%
880697-5002S Turbo G30-660 - 880697-5002S
Loppu varastosta
54mm 67mm 65 0.70 60mm 55mm 84 0.83 V-Band V-Band No No Standard
1909.00 € 1539.52 € alv. 0%
880697-5001S Turbo G30-660 - 880697-5001S
Loppu varastosta
54mm 67mm 65 0.70 60mm 55mm 84 0.61 V-Band V-Band No No Standard
1909.00 € 1539.52 € alv. 0%
880704-5003S Turbo G30-660 - 880704-5003S
Loppu varastosta
54mm 67mm 65 0.70 60mm 55mm 84 1.01 V-Band V-Band Yes No Standard
2039.00 € 1644.35 € alv. 0%
Compressor    Turbine   Turbine kit
Turbo PN Inducer Exducer Trim A/R Inducer Exducer Trim A/R Inlet Outlet Wastegate Divided Hinta
Turbo PN: 880704-5002S
2039.00 € 1644.35 € alv. 0%
880704-5002S
Compressor    Inducer
54mm 		Exducer
67mm		 Trim
65		 A/R
0.70		 Turbine    Inducer
60mm 		Exducer
55mm		 Trim
84		 Turbine kit    A/R
0.83 		Inlet
V-Band		 Outlet
V-Band		 Wastegate
Yes		 Divided
No
2039.00 €
Rotation: Standard Loppu varastosta | 1644.35 € alv. 0%
Turbo PN: 880697-5003S
1909.00 € 1539.52 € alv. 0%
880697-5003S
Compressor    Inducer
54mm 		Exducer
67mm		 Trim
65		 A/R
0.70		 Turbine    Inducer
60mm 		Exducer
55mm		 Trim
84		 Turbine kit    A/R
1.01 		Inlet
V-Band		 Outlet
V-Band		 Wastegate
No		 Divided
No
1909.00 €
Rotation: Standard Loppu varastosta | 1539.52 € alv. 0%
Turbo PN: 880697-5002S
1909.00 € 1539.52 € alv. 0%
880697-5002S
Compressor    Inducer
54mm 		Exducer
67mm		 Trim
65		 A/R
0.70		 Turbine    Inducer
60mm 		Exducer
55mm		 Trim
84		 Turbine kit    A/R
0.83 		Inlet
V-Band		 Outlet
V-Band		 Wastegate
No		 Divided
No
1909.00 €
Rotation: Standard Loppu varastosta | 1539.52 € alv. 0%
Turbo PN: 880697-5001S
1909.00 € 1539.52 € alv. 0%
880697-5001S
Compressor    Inducer
54mm 		Exducer
67mm		 Trim
65		 A/R
0.70		 Turbine    Inducer
60mm 		Exducer
55mm		 Trim
84		 Turbine kit    A/R
0.61 		Inlet
V-Band		 Outlet
V-Band		 Wastegate
No		 Divided
No
1909.00 €
Rotation: Standard Loppu varastosta | 1539.52 € alv. 0%
Turbo PN: 880704-5003S
2039.00 € 1644.35 € alv. 0%
880704-5003S
Compressor    Inducer
54mm 		Exducer
67mm		 Trim
65		 A/R
0.70		 Turbine    Inducer
60mm 		Exducer
55mm		 Trim
84		 Turbine kit    A/R
1.01 		Inlet
V-Band		 Outlet
V-Band		 Wastegate
Yes		 Divided
No
2039.00 €
Rotation: Standard Loppu varastosta | 1644.35 € alv. 0%
