GTX3584RS GEN II

GTX3584RS GEN II

Horsepower: 550 - 1000

Displacement: 2.0L - 5.5L

Features:

  • Gen II aerodynamics feature increased horsepower range
  • "RS" designed, high horsepower turbine wheel
  • Compact design for tight installations
  • New fully-machined speed sensor port
  • Compressor outlet available in V-Band & Hose connection
*GTX3584RS Turbine housings are not compatible
 with other GT35R/GTX35R Housings

Hose Compressor Outlet:

  • 856804-5001S
  • 856804-5002S
  • 856804-5003S

V-Band Compressor Outlet:

  • 856804-5004S
  • 856804-5005S
  • 856804-5006S
Turbocharger includes FREE gasket kit

Turbocharger

Compressor    Turbine   Turbine kit
Turbo PN Inducer Exducer Trim A/R Inducer Exducer Trim A/R Inlet Outlet Wastegate Divided Rotation Hinta
856804-5006S Turbo GTX3584RS Gen II - 856804-5006S
Loppu varastosta
67mm 84mm 64 0.72 68mm 62mm 84 1.21 V-Band V-Band No No Standard
2309.00 € 1862.10 € alv. 0%
856804-5005S Turbo GTX3584RS Gen II - 856804-5005S
Loppu varastosta
67mm 84mm 64 0.72 68mm 62mm 84 1.01 V-Band V-Band No No Standard
2309.00 € 1862.10 € alv. 0%
856804-5004S Turbo GTX3584RS Gen II - 856804-5004S
Loppu varastosta
67mm 84mm 64 0.72 68mm 62mm 84 0.83 V-Band V-Band No No Standard
2309.00 € 1862.10 € alv. 0%
856804-5003S Turbo GTX3584RS Gen II - 856804-5003S
Loppu varastosta
67mm 84mm 64 0.72 68mm 62mm 84 1.21 V-Band V-Band No No Standard
2309.00 € 1862.10 € alv. 0%
856804-5002S Turbo GTX3584RS Gen II - 856804-5002S
Loppu varastosta
67mm 84mm 64 0.72 68mm 62mm 84 1.01 V-Band V-Band No No Standard
2309.00 € 1862.10 € alv. 0%
856804-5001S Turbo GTX3584RS Gen II - 856804-5001S
Loppu varastosta
67mm 84mm 64 0.72 68mm 62mm 84 0.83 V-Band V-Band No No Standard
2309.00 € 1862.10 € alv. 0%
Compressor    Turbine   Turbine kit
Turbo PN Inducer Exducer Trim A/R Inducer Exducer Trim A/R Inlet Outlet Wastegate Divided Hinta
Turbo PN: 856804-5006S
2309.00 € 1862.10 € alv. 0%
856804-5006S
Compressor    Inducer
67mm 		Exducer
84mm		 Trim
64		 A/R
0.72		 Turbine    Inducer
68mm 		Exducer
62mm		 Trim
84		 Turbine kit    A/R
1.21 		Inlet
 V-Band		 Outlet
V-Band		 Wastegate
No		 Divided
No
2309.00 €
Rotation: Standard Loppu varastosta | 1862.10 € alv. 0%
Turbo PN: 856804-5005S
2309.00 € 1862.10 € alv. 0%
856804-5005S
Compressor    Inducer
67mm 		Exducer
84mm		 Trim
64		 A/R
0.72		 Turbine    Inducer
68mm 		Exducer
62mm		 Trim
84		 Turbine kit    A/R
1.01 		Inlet
 V-Band		 Outlet
V-Band		 Wastegate
No		 Divided
No
2309.00 €
Rotation: Standard Loppu varastosta | 1862.10 € alv. 0%
Turbo PN: 856804-5004S
2309.00 € 1862.10 € alv. 0%
856804-5004S
Compressor    Inducer
67mm 		Exducer
84mm		 Trim
64		 A/R
0.72		 Turbine    Inducer
68mm 		Exducer
62mm		 Trim
84		 Turbine kit    A/R
0.83 		Inlet
 V-Band		 Outlet
V-Band		 Wastegate
No		 Divided
No
2309.00 €
Rotation: Standard Loppu varastosta | 1862.10 € alv. 0%
Turbo PN: 856804-5003S
2309.00 € 1862.10 € alv. 0%
856804-5003S
Compressor    Inducer
67mm 		Exducer
84mm		 Trim
64		 A/R
0.72		 Turbine    Inducer
68mm 		Exducer
62mm		 Trim
84		 Turbine kit    A/R
1.21 		Inlet
 V-Band		 Outlet
V-Band		 Wastegate
No		 Divided
No
2309.00 €
Rotation: Standard Loppu varastosta | 1862.10 € alv. 0%
Turbo PN: 856804-5002S
2309.00 € 1862.10 € alv. 0%
856804-5002S
Compressor    Inducer
67mm 		Exducer
84mm		 Trim
64		 A/R
0.72		 Turbine    Inducer
68mm 		Exducer
62mm		 Trim
84		 Turbine kit    A/R
1.01 		Inlet
 V-Band		 Outlet
V-Band		 Wastegate
No		 Divided
No
2309.00 €
Rotation: Standard Loppu varastosta | 1862.10 € alv. 0%
Turbo PN: 856804-5001S
2309.00 € 1862.10 € alv. 0%
856804-5001S
Compressor    Inducer
67mm 		Exducer
84mm		 Trim
64		 A/R
0.72		 Turbine    Inducer
68mm 		Exducer
62mm		 Trim
84		 Turbine kit    A/R
0.83 		Inlet
 V-Band		 Outlet
V-Band		 Wastegate
No		 Divided
No
2309.00 €
Rotation: Standard Loppu varastosta | 1862.10 € alv. 0%
