GTX3071R GEN II

GTX3071R GEN II

Horsepower: 340 - 675

Displacement: 1.8L - 3.0L

Features:

  • Gen II aerodynamics feature increased horsepower range
  • Improved ported shroud design for surge resistance
  • New fully machined speed sensor port
  • New reverse rotation configurations available
Turbocharger includes FREE gasket kit

Turbocharger

Compressor    Turbine   Turbine kit
Turbo PN Inducer Exducer Trim A/R Inducer Exducer Trim A/R Inlet Outlet Wastegate Divided Rotation Hinta
856801-5021S Turbo GTX3071R Gen II - 856801-5021S
Loppu varastosta
54mm 71mm 58 0.60 60mm 55mm 84 0.63 T3 5-Bolt Yes No Standard
1599.00 € 1289.52 € alv. 0%
856801-5020S Turbo GTX3071R Gen II - 856801-5020S
Loppu varastosta
54mm 71mm 58 0.60 60mm 55mm 84 0.82 T3 5-Bolt Yes No Standard
1599.00 € 1289.52 € alv. 0%
856801-5019S Turbo GTX3071R Gen II - 856801-5019S
Loppu varastosta
54mm 71mm 58 0.60 60mm 55mm 84 1.06 T3 5-Bolt Yes No Standard
1599.00 € 1289.52 € alv. 0%
856801-5018S Turbo GTX3071R Gen II - 856801-5018S
Loppu varastosta
54mm 71mm 58 0.60 60mm 55mm 84 0.61 V-Band V-Band No No Standard
1639.00 € 1321.77 € alv. 0%
856801-5017S Turbo GTX3071R Gen II - 856801-5017S
Varastossa
54mm 71mm 58 0.60 60mm 55mm 84 0.83 V-Band V-Band No No Standard
1639.00 € 1321.77 € alv. 0%
856801-5016S Turbo GTX3071R Gen II - 856801-5016S
Loppu varastosta
54mm 71mm 58 0.60 60mm 55mm 84 1.01 V-Band V-Band No No Standard
1639.00 € 1321.77 € alv. 0%
856801-5006S Turbo GTX3071R Gen II - 856801-5006S
Loppu varastosta
54mm 71mm 58 0.60 60mm 55mm 84 0.63 T3 V-Band No No Standard
1599.00 € 1289.52 € alv. 0%
856801-5005S Turbo GTX3071R Gen II - 856801-5005S
Loppu varastosta
54mm 71mm 58 0.60 60mm 55mm 84 0.82 T3 V-Band No No Standard
1599.00 € 1289.52 € alv. 0%
856801-5004S Turbo GTX3071R Gen II - 856801-5004S
Loppu varastosta
54mm 71mm 58 0.60 60mm 55mm 84 1.06 T3 V-Band No No Standard
1599.00 € 1289.52 € alv. 0%
856801-5014S Turbo GTX3071R Gen II - 856801-5014S
Loppu varastosta
1849.00 € 1491.13 € alv. 0%
Compressor    Turbine   Turbine kit
Turbo PN Inducer Exducer Trim A/R Inducer Exducer Trim A/R Inlet Outlet Wastegate Divided Hinta
Turbo PN: 856801-5021S
1599.00 € 1289.52 € alv. 0%
856801-5021S
Compressor    Inducer
54mm
Exducer
71mm
Trim
58
A/R
0.60
Turbine    Inducer
60mm
Exducer
55mm
Trim
84
Turbine kit    A/R
0.63
Inlet
T3
Outlet
5-Bolt
Wastegate
Yes
Divided
No
1599.00 €
Rotation: Standard Loppu varastosta | 1289.52 € alv. 0%
Turbo PN: 856801-5020S
1599.00 € 1289.52 € alv. 0%
856801-5020S
Compressor    Inducer
54mm
Exducer
71mm
Trim
58
A/R
0.60
Turbine    Inducer
60mm
Exducer
55mm
Trim
84
Turbine kit    A/R
0.82
Inlet
T3
Outlet
5-Bolt
Wastegate
Yes
Divided
No
1599.00 €
Rotation: Standard Loppu varastosta | 1289.52 € alv. 0%
Turbo PN: 856801-5019S
1599.00 € 1289.52 € alv. 0%
856801-5019S
Compressor    Inducer
54mm
Exducer
71mm
Trim
58
A/R
0.60
Turbine    Inducer
60mm
Exducer
55mm
Trim
84
Turbine kit    A/R
1.06
Inlet
T3
Outlet
5-Bolt
Wastegate
Yes
Divided
No
1599.00 €
Rotation: Standard Loppu varastosta | 1289.52 € alv. 0%
Turbo PN: 856801-5018S
1639.00 € 1321.77 € alv. 0%
856801-5018S
Compressor    Inducer
54mm
Exducer
71mm
Trim
58
A/R
0.60
Turbine    Inducer
60mm
Exducer
55mm
Trim
84
Turbine kit    A/R
0.61
Inlet
V-Band
Outlet
V-Band
Wastegate
No
Divided
No
1639.00 €
Rotation: Standard Loppu varastosta | 1321.77 € alv. 0%
Turbo PN: 856801-5017S
1639.00 € 1321.77 € alv. 0%
856801-5017S
Compressor    Inducer
54mm
Exducer
71mm
Trim
58
A/R
0.60
Turbine    Inducer
60mm
Exducer
55mm
Trim
84
Turbine kit    A/R
0.83
Inlet
V-Band
Outlet
V-Band
Wastegate
No
Divided
No
1639.00 €
Rotation: Standard Varastossa | 1321.77 € alv. 0%
Turbo PN: 856801-5016S
1639.00 € 1321.77 € alv. 0%
856801-5016S
Compressor    Inducer
54mm
Exducer
71mm
Trim
58
A/R
0.60
Turbine    Inducer
60mm
Exducer
55mm
Trim
84
Turbine kit    A/R
1.01
Inlet
V-Band
Outlet
V-Band
Wastegate
No
Divided
No
1639.00 €
Rotation: Standard Loppu varastosta | 1321.77 € alv. 0%
Turbo PN: 856801-5006S
1599.00 € 1289.52 € alv. 0%
856801-5006S
Compressor    Inducer
54mm
Exducer
71mm
Trim
58
A/R
0.60
Turbine    Inducer
60mm
Exducer
55mm
Trim
84
Turbine kit    A/R
0.63
Inlet
T3
Outlet
V-Band
Wastegate
No
Divided
No
1599.00 €
Rotation: Standard Loppu varastosta | 1289.52 € alv. 0%
Turbo PN: 856801-5005S
1599.00 € 1289.52 € alv. 0%
856801-5005S
Compressor    Inducer
54mm
Exducer
71mm
Trim
58
A/R
0.60
Turbine    Inducer
60mm
Exducer
55mm
Trim
84
Turbine kit    A/R
0.82
Inlet
T3
Outlet
V-Band
Wastegate
No
Divided
No
1599.00 €
Rotation: Standard Loppu varastosta | 1289.52 € alv. 0%
Turbo PN: 856801-5004S
1599.00 € 1289.52 € alv. 0%
856801-5004S
Compressor    Inducer
54mm
Exducer
71mm
Trim
58
A/R
0.60
Turbine    Inducer
60mm
Exducer
55mm
Trim
84
Turbine kit    A/R
1.06
Inlet
T3
Outlet
V-Band
Wastegate
No
Divided
No
1599.00 €
Rotation: Standard Loppu varastosta | 1289.52 € alv. 0%
Turbo PN: 856801-5014S
1849.00 € 1491.13 € alv. 0%
856801-5014S
Compressor    Inducer
Exducer
Trim
A/R
Turbine    Inducer
Exducer
Trim
Turbine kit    A/R
Inlet
Outlet
Wastegate
Divided
1849.00 €
Rotation: Loppu varastosta | 1491.13 € alv. 0%

Actuator Assembly

480009-0006
69.00 €
55.65 € alv. 0% | Loppu varastosta
