GTX2867R GEN II

GTX2867R GEN II

Horsepower: 275 - 550

Displacement: 1.4L - 2.5L

Features:

  • Gen II aerodynamics feature increased horsepower range
  • Improved ported shroud design for surge resistance
  • New fully machined speed sensor port
Turbocharger includes FREE gasket kit

Turbocharger

Compressor    Turbine   Turbine kit
Turbo PN Inducer Exducer Trim A/R Inducer Exducer Trim A/R Inlet Outlet Wastegate Divided Rotation Hinta
856800-5006S Turbo GTX2867R Gen II - 856800-5006S
Loppu varastosta
50mm 67mm 55 0.60 54mm 47mm 76 0.72 V-Band V-Band No No Standard
1589.00 € 1281.45 € alv. 0%
856800-5007S Turbo GTX2867R Gen II - 856800-5007S
Loppu varastosta
50mm 67mm 55 0.60 54mm 47mm 76 0.64 T25 5-Bolt Yes No Standard
1499.00 € 1208.87 € alv. 0%
856800-5008S Turbo GTX2867R Gen II - 856800-5008S
Loppu varastosta
50mm 67mm 55 0.60 54mm 47mm 76 0.86 T25 5-Bolt Yes No Standard
1499.00 € 1208.87 € alv. 0%
856800-5005S Turbo GTX2867R Gen II - 856800-5005S
Loppu varastosta
50mm 67mm 55 0.60 54mm 47mm 76 0.57 V-Band V-Band No No Standard
1589.00 € 1281.45 € alv. 0%
Compressor    Turbine   Turbine kit
Turbo PN Inducer Exducer Trim A/R Inducer Exducer Trim A/R Inlet Outlet Wastegate Divided Hinta
Turbo PN: 856800-5006S
1589.00 € 1281.45 € alv. 0%
856800-5006S
Compressor    Inducer
50mm 		Exducer
67mm		 Trim
55		 A/R
0.60		 Turbine    Inducer
54mm 		Exducer
47mm		 Trim
76		 Turbine kit    A/R
0.72 		Inlet
 V-Band		 Outlet
V-Band		 Wastegate
No		 Divided
No
1589.00 €
Rotation: Standard Loppu varastosta | 1281.45 € alv. 0%
Turbo PN: 856800-5007S
1499.00 € 1208.87 € alv. 0%
856800-5007S
Compressor    Inducer
50mm 		Exducer
67mm		 Trim
55		 A/R
0.60		 Turbine    Inducer
54mm 		Exducer
47mm		 Trim
76		 Turbine kit    A/R
0.64 		Inlet
 T25		 Outlet
5-Bolt		 Wastegate
Yes		 Divided
No
1499.00 €
Rotation: Standard Loppu varastosta | 1208.87 € alv. 0%
Turbo PN: 856800-5008S
1499.00 € 1208.87 € alv. 0%
856800-5008S
Compressor    Inducer
50mm 		Exducer
67mm		 Trim
55		 A/R
0.60		 Turbine    Inducer
54mm 		Exducer
47mm		 Trim
76		 Turbine kit    A/R
0.86 		Inlet
 T25		 Outlet
5-Bolt		 Wastegate
Yes		 Divided
No
1499.00 €
Rotation: Standard Loppu varastosta | 1208.87 € alv. 0%
Turbo PN: 856800-5005S
1589.00 € 1281.45 € alv. 0%
856800-5005S
Compressor    Inducer
50mm 		Exducer
67mm		 Trim
55		 A/R
0.60		 Turbine    Inducer
54mm 		Exducer
47mm		 Trim
76		 Turbine kit    A/R
0.57 		Inlet
 V-Band		 Outlet
V-Band		 Wastegate
No		 Divided
No
1589.00 €
Rotation: Standard Loppu varastosta | 1281.45 € alv. 0%

Actuator Assembly

480009-0009
89.00 €
71.77 € alv. 0% | Loppu varastosta
480009-0006
89.00 €
71.77 € alv. 0% | Loppu varastosta
