GTW3684R

GTW3684R

Horsepower: 425 - 750

Displacement: 2.0L - 5.3L

Features:

  • Ported shroud design for surge resistance
  • Available in both journal bearing and ball bearing options
  • Forger fully-machined billet compressor wheel
  • Turbine housings available in divided configuration
  • Lightweight aluminium backplate

*841279 Journal Bearing Option

*841691 Ball Bearing Option

Turbocharger includes FREE gasket kit

Super Core

Compressor    Turbine
Super Core PN Inducer Exducer Trim A/R Inducer Exducer Trim Rotation Hinta
841691-5002S
Loppu varastosta
62mm 84mm 54 0.70 71mm 62mm 76 Standard
1199.00 € 966.94 € alv. 0%
841297-5002S
Loppu varastosta
62mm 84mm 54 0.70 71mm 62mm 76 Standard
729.00 € 587.90 € alv. 0%
Compressor    Turbine
Super Core PN Inducer Exducer Trim A/R Inducer Exducer Trim Hinta
Turbo PN: 841691-5002S
1199.00 € 966.94 € alv. 0%
841691-5002S
Compressor Inducer
62mm 		Exducer
84mm		 Trim
54		 A/R
0.70		 Turbine Inducer
71mm 		Exducer
62mm		 Trim
76
1199.00 €
Rotation: Standard Loppu varastosta | 966.94 € alv. 0%
Turbo PN: 841297-5002S
729.00 € 587.90 € alv. 0%
841297-5002S
Compressor Inducer
62mm 		Exducer
84mm		 Trim
54		 A/R
0.70		 Turbine Inducer
71mm 		Exducer
62mm		 Trim
76
729.00 €
Rotation: Standard Loppu varastosta | 587.90 € alv. 0%

Turbine Hsg

Non Wastegate
Turbine Kit PN A/R Inlet Outlet Wastegate Divided Trim Rotation Hinta
844669-0007
Loppu varastosta
1.15 T4 V-Band No Yes 76 Standard
329.00 € 265.32 € alv. 0%
844669-0006
Loppu varastosta
1.00 T4 V-Band No Yes 76 Standard
299.00 € 241.13 € alv. 0%
844669-0005
Loppu varastosta
0.70 T4 V-Band No Yes 76 Standard
329.00 € 265.32 € alv. 0%
Turbine Kit PN A/R Inlet Outlet Wastegate Divided Trim Hinta
Turbine Kit PN: 844669-0007
329.00 € 265.32 € alv. 0%
844669-0007
A/R
1.15		 Inlet
 T4		 Outlet
V-Band		 Wastegate
No		 Divided
Yes		 Trim
76
329.00 €
Rotation: Standard Loppu varastosta | 265.32 € alv. 0%
Turbine Kit PN: 844669-0006
299.00 € 241.13 € alv. 0%
844669-0006
A/R
1.00		 Inlet
 T4		 Outlet
V-Band		 Wastegate
No		 Divided
Yes		 Trim
76
299.00 €
Rotation: Standard Loppu varastosta | 241.13 € alv. 0%
Turbine Kit PN: 844669-0005
329.00 € 265.32 € alv. 0%
844669-0005
A/R
0.70		 Inlet
 T4		 Outlet
V-Band		 Wastegate
No		 Divided
Yes		 Trim
76
329.00 €
Rotation: Standard Loppu varastosta | 265.32 € alv. 0%
