GTW3476R

GTW3476R

Horsepower: 450 - 700

Displacement: 2.0L - 4.5L

Features:

  • Ported shroud design for surge resistance
  • Available in both journal bearing and ball bearing options
  • Forged fully-machined billet compressor wheel
  • Lightweight aluminium backplate
  • Inconel Super-alloy turbine wheel

*841279 Journal Bearing Option

*841691 Ball Bearing Option

Turbocharger includes FREE gasket kit

Super Core

Compressor    Turbine
Super Core PN Inducer Exducer Trim A/R Inducer Exducer Trim Rotation Hinta
841691-5001S
Loppu varastosta
58mm 76mm 58 0.70 65mm 57mm 76 Standard
1139.00 € 918.55 € alv. 0%
841297-5001S
Loppu varastosta
58mm 76mm 58 0.70 65mm 57mm 76 Standard
699.00 € 563.71 € alv. 0%
Compressor    Turbine
Super Core PN Inducer Exducer Trim A/R Inducer Exducer Trim Hinta
Turbo PN: 841691-5001S
1139.00 € 918.55 € alv. 0%
841691-5001S
Compressor Inducer
58mm 		Exducer
76mm		 Trim
58		 A/R
0.70		 Turbine Inducer
65mm 		Exducer
57mm		 Trim
76
1139.00 €
Rotation: Standard Loppu varastosta | 918.55 € alv. 0%
Turbo PN: 841297-5001S
699.00 € 563.71 € alv. 0%
841297-5001S
Compressor Inducer
58mm 		Exducer
76mm		 Trim
58		 A/R
0.70		 Turbine Inducer
65mm 		Exducer
57mm		 Trim
76
699.00 €
Rotation: Standard Loppu varastosta | 563.71 € alv. 0%

Turbine Hsg

Non Wastegate
Turbine Kit PN A/R Inlet Outlet Wastegate Divided Trim Rotation Hinta
844669-0003
Loppu varastosta
0.82 T3 4-Bolt No No 76 Standard
279.00 € 225.00 € alv. 0%
844669-0002
Loppu varastosta
0.63 T3 4-Bolt No No 76 Standard
279.00 € 225.00 € alv. 0%
844669-0001
Loppu varastosta
0.48 T3 4-Bolt No No 76 Standard
279.00 € 225.00 € alv. 0%
Turbine Kit PN A/R Inlet Outlet Wastegate Divided Trim Hinta
Turbine Kit PN: 844669-0003
279.00 € 225.00 € alv. 0%
844669-0003
A/R
0.82		 Inlet
 T3		 Outlet
4-Bolt		 Wastegate
No		 Divided
No		 Trim
76
279.00 €
Rotation: Standard Loppu varastosta | 225.00 € alv. 0%
Turbine Kit PN: 844669-0002
279.00 € 225.00 € alv. 0%
844669-0002
A/R
0.63		 Inlet
 T3		 Outlet
4-Bolt		 Wastegate
No		 Divided
No		 Trim
76
279.00 €
Rotation: Standard Loppu varastosta | 225.00 € alv. 0%
Turbine Kit PN: 844669-0001
279.00 € 225.00 € alv. 0%
844669-0001
A/R
0.48		 Inlet
 T3		 Outlet
4-Bolt		 Wastegate
No		 Divided
No		 Trim
76
279.00 €
Rotation: Standard Loppu varastosta | 225.00 € alv. 0%
