GT3071R

GT3071R

Horsepower: 280 - 480

Displacement: 2.5L - 3.5L

Features:

  • Original GT Series aerodynamics
  • Internally wastegated turbine housings available
  • Water cooled CHRA
  • V-Band turbine housind options
Turbocharger includes FREE gasket kit
  • 836028-5001S   2.75'' Inlet
  • 836028-5004S  2.75'' Inlet
  • 836028-5002S  4.00'' Inlet
  • 836028-5005S  4.00'' Inlet

Super Core

Compressor    Turbine
Super Core PN Inducer Exducer Trim A/R Inducer Exducer Trim Rotation Hinta
836028-5001S
Loppu varastosta
53mm 71mm 56 0.50 60mm 55mm 84 Standard
769.00 € 620.16 € alv. 0%
836028-5005S
Loppu varastosta
53mm 71mm 56 0.50 60mm 55mm 84 Standard
769.00 € 620.16 € alv. 0%
836028-5004S
Loppu varastosta
53mm 71mm 56 0.50 60mm 55mm 84 Standard
769.00 € 620.16 € alv. 0%
836028-5002S
Loppu varastosta
53mm 71mm 56 0.50 60mm 55mm 84 Standard
769.00 € 620.16 € alv. 0%
Compressor    Turbine
Super Core PN Inducer Exducer Trim A/R Inducer Exducer Trim Hinta
Turbo PN: 836028-5001S
769.00 € 620.16 € alv. 0%
836028-5001S
Compressor Inducer
53mm 		Exducer
71mm		 Trim
56		 A/R
0.50		 Turbine Inducer
60mm 		Exducer
55mm		 Trim
84
769.00 €
Rotation: Standard Loppu varastosta | 620.16 € alv. 0%
Turbo PN: 836028-5005S
769.00 € 620.16 € alv. 0%
836028-5005S
Compressor Inducer
53mm 		Exducer
71mm		 Trim
56		 A/R
0.50		 Turbine Inducer
60mm 		Exducer
55mm		 Trim
84
769.00 €
Rotation: Standard Loppu varastosta | 620.16 € alv. 0%
Turbo PN: 836028-5004S
769.00 € 620.16 € alv. 0%
836028-5004S
Compressor Inducer
53mm 		Exducer
71mm		 Trim
56		 A/R
0.50		 Turbine Inducer
60mm 		Exducer
55mm		 Trim
84
769.00 €
Rotation: Standard Loppu varastosta | 620.16 € alv. 0%
Turbo PN: 836028-5002S
769.00 € 620.16 € alv. 0%
836028-5002S
Compressor Inducer
53mm 		Exducer
71mm		 Trim
56		 A/R
0.50		 Turbine Inducer
60mm 		Exducer
55mm		 Trim
84
769.00 €
Rotation: Standard Loppu varastosta | 620.16 € alv. 0%

Turbine Hsg

Non Wastegate
Turbine Kit PN A/R Inlet Outlet Wastegate Divided Trim Rotation Hinta
740902-0007
Loppu varastosta
1.06 T3 V-Band No No 84 Standard
459.00 € 370.16 € alv. 0%
740902-0003
Loppu varastosta
0.63 T3 4-Bolt No No 84 Standard
449.00 € 362.10 € alv. 0%
740902-0036
Loppu varastosta
0.61 V-Band V-Band No No 84 Standard
489.00 € 394.35 € alv. 0%
740902-0035
Loppu varastosta
0.83 V-Band V-Band No No 84 Standard
489.00 € 394.35 € alv. 0%
740902-0034
Loppu varastosta
1.01 V-Band V-Band No No 84 Standard
489.00 € 394.35 € alv. 0%
740902-0024
Loppu varastosta
0.61 V-Band V-Band No Yes 84 Standard
529.00 € 426.61 € alv. 0%
740902-0023
Loppu varastosta
0.83 V-Band V-Band No Yes 84 Standard
529.00 € 426.61 € alv. 0%
740902-0022
Loppu varastosta
1.01 V-Band V-Band No Yes 84 Standard
529.00 € 426.61 € alv. 0%
740902-0015
Loppu varastosta
0.63 T4 V-Band No No 84 Standard
469.00 € 378.23 € alv. 0%
740902-0014
Loppu varastosta
0.82 T4 V-Band No No 84 Standard
469.00 € 378.23 € alv. 0%
740902-0002
Loppu varastosta
0.82 T3 4-Bolt No No 84 Standard
449.00 € 362.10 € alv. 0%
740902-0001
Loppu varastosta
1.06 T3 4-Bolt No No 84 Standard
489.00 € 394.35 € alv. 0%
TIALVB3082
Varastossa
0.82 V-Band V-Band No No 84 Standard
469.00 € 378.23 € alv. 0%
TIALVB3063
Varastossa
0.63 V-Band V-Band No No 84 Standard
469.00 € 378.23 € alv. 0%
TIALVB30106
Loppu varastosta
1.06 V-Band V-Band No No 84 Standard
469.00 € 378.23 € alv. 0%
740902-0009
Varastossa
0.63 T3 V-Band No No 84 Standard
449.00 € 362.10 € alv. 0%
740902-0008
Varastossa
0.82 T3 V-Band No No 84 Standard
449.00 € 362.10 € alv. 0%
Turbine Kit PN A/R Inlet Outlet Wastegate Divided Trim Hinta
Turbine Kit PN: 740902-0007
459.00 € 370.16 € alv. 0%
740902-0007
A/R
1.06		 Inlet
 T3		 Outlet
V-Band		 Wastegate
No		 Divided
No		 Trim
84
459.00 €
Rotation: Standard Loppu varastosta | 370.16 € alv. 0%
Turbine Kit PN: 740902-0003
449.00 € 362.10 € alv. 0%
740902-0003
A/R
0.63		 Inlet
T3		 Outlet
4-Bolt		 Wastegate
No		 Divided
No		 Trim
84
449.00 €
Rotation: Standard Loppu varastosta | 362.10 € alv. 0%
Turbine Kit PN: 740902-0036
489.00 € 394.35 € alv. 0%
740902-0036
A/R
0.61		 Inlet
 V-Band		 Outlet
V-Band		 Wastegate
No		 Divided
No		 Trim
84
489.00 €
Rotation: Standard Loppu varastosta | 394.35 € alv. 0%
Turbine Kit PN: 740902-0035
489.00 € 394.35 € alv. 0%
740902-0035
A/R
0.83		 Inlet
 V-Band		 Outlet
V-Band		 Wastegate
No		 Divided
No		 Trim
84
489.00 €
Rotation: Standard Loppu varastosta | 394.35 € alv. 0%
Turbine Kit PN: 740902-0034
489.00 € 394.35 € alv. 0%
740902-0034
A/R
1.01		 Inlet
 V-Band		 Outlet
V-Band		 Wastegate
No		 Divided
No		 Trim
84
489.00 €
Rotation: Standard Loppu varastosta | 394.35 € alv. 0%
Turbine Kit PN: 740902-0024
529.00 € 426.61 € alv. 0%
740902-0024
A/R
0.61		 Inlet
V-Band		 Outlet
V-Band		 Wastegate
No		 Divided
Yes		 Trim
84
529.00 €
Rotation: Standard Loppu varastosta | 426.61 € alv. 0%
Turbine Kit PN: 740902-0023
529.00 € 426.61 € alv. 0%
740902-0023
A/R
0.83		 Inlet
V-Band		 Outlet
V-Band		 Wastegate
No		 Divided
Yes		 Trim
84
529.00 €
Rotation: Standard Loppu varastosta | 426.61 € alv. 0%
Turbine Kit PN: 740902-0022
529.00 € 426.61 € alv. 0%
740902-0022
A/R
1.01		 Inlet
V-Band		 Outlet
V-Band		 Wastegate
No		 Divided
Yes		 Trim
84
529.00 €
Rotation: Standard Loppu varastosta | 426.61 € alv. 0%
Turbine Kit PN: 740902-0015
469.00 € 378.23 € alv. 0%
740902-0015
A/R
0.63		 Inlet
T4		 Outlet
V-Band		 Wastegate
No		 Divided
No		 Trim
84
469.00 €
Rotation: Standard Loppu varastosta | 378.23 € alv. 0%
Turbine Kit PN: 740902-0014
469.00 € 378.23 € alv. 0%
740902-0014
A/R
0.82		 Inlet
T4		 Outlet
V-Band		 Wastegate
No		 Divided
No		 Trim
84
469.00 €
Rotation: Standard Loppu varastosta | 378.23 € alv. 0%
Turbine Kit PN: 740902-0002
449.00 € 362.10 € alv. 0%
740902-0002
A/R
0.82		 Inlet
T3		 Outlet
4-Bolt		 Wastegate
No		 Divided
No		 Trim
84
449.00 €
Rotation: Standard Loppu varastosta | 362.10 € alv. 0%
Turbine Kit PN: 740902-0001
489.00 € 394.35 € alv. 0%
740902-0001
A/R
1.06		 Inlet
T3		 Outlet
4-Bolt		 Wastegate
No		 Divided
No		 Trim
84
489.00 €
Rotation: Standard Loppu varastosta | 394.35 € alv. 0%
Turbine Kit PN: TIALVB3082
469.00 € 378.23 € alv. 0%
TIALVB3082
A/R
0.82		 Inlet
V-Band		 Outlet
V-Band		 Wastegate
No		 Divided
No		 Trim
84
469.00 €
Rotation: Standard Varastossa | 378.23 € alv. 0%
Turbine Kit PN: TIALVB3063
469.00 € 378.23 € alv. 0%
TIALVB3063
A/R
0.63		 Inlet
V-Band		 Outlet
V-Band		 Wastegate
No		 Divided
No		 Trim
84
469.00 €
Rotation: Standard Varastossa | 378.23 € alv. 0%
Turbine Kit PN: TIALVB30106
469.00 € 378.23 € alv. 0%
TIALVB30106
A/R
1.06		 Inlet
V-Band		 Outlet
V-Band		 Wastegate
No		 Divided
No		 Trim
84
469.00 €
Rotation: Standard Loppu varastosta | 378.23 € alv. 0%
Turbine Kit PN: 740902-0009
449.00 € 362.10 € alv. 0%
740902-0009
A/R
0.63		 Inlet
 T3		 Outlet
V-Band		 Wastegate
No		 Divided
No		 Trim
84
449.00 €
Rotation: Standard Varastossa | 362.10 € alv. 0%
Turbine Kit PN: 740902-0008
449.00 € 362.10 € alv. 0%
740902-0008
A/R
0.82		 Inlet
 T3		 Outlet
V-Band		 Wastegate
No		 Divided
No		 Trim
84
449.00 €
Rotation: Standard Varastossa | 362.10 € alv. 0%
Wastegate
Turbine Kit PN A/R Inlet Outlet Wastegate Divided Trim Rotation Hinta
771300-0006
Varastossa
0.63 T3 5-Bolt Yes No 84 Standard
479.00 € 386.29 € alv. 0%
771300-0005
Loppu varastosta
0.82 T3 5-Bolt Yes No 84 Standard
459.00 € 370.16 € alv. 0%
771300-0004
Loppu varastosta
1.06 T3 5-Bolt Yes No 84 Standard
499.00 € 402.42 € alv. 0%
Turbine Kit PN A/R Inlet Outlet Wastegate Divided Trim Hinta
Turbine Kit PN: 771300-0006
479.00 € 386.29 € alv. 0%
771300-0006
A/R
0.63		 Inlet
 T3		 Outlet
5-Bolt		 Wastegate
Yes		 Divided
No		 Trim
84
479.00 €
Rotation: Standard Varastossa | 386.29 € alv. 0%
Turbine Kit PN: 771300-0005
459.00 € 370.16 € alv. 0%
771300-0005
A/R
0.82		 Inlet
 T3		 Outlet
5-Bolt		 Wastegate
Yes		 Divided
No		 Trim
84
459.00 €
Rotation: Standard Loppu varastosta | 370.16 € alv. 0%
Turbine Kit PN: 771300-0004
499.00 € 402.42 € alv. 0%
771300-0004
A/R
1.06		 Inlet
 T3		 Outlet
5-Bolt		 Wastegate
Yes		 Divided
No		 Trim
84
499.00 €
Rotation: Standard Loppu varastosta | 402.42 € alv. 0%

Actuator Assembly

480009-0006
69.00 €
55.65 € alv. 0% | Varastossa
