GBC35-700

GBC35-700

Horsepower: 400 - 700

Displacement: 2.0L - 5.0L

Features:

  • Billet compressor wheel with extended tip design for higher pressure ratios
  • 58mm compressor wheel with GTX Gen II compressor aerodynamics
  • Journal bearing rotating group with 360-degree thrust bearing
  • Outline interchangeable with GBC37-900 for stage upgrades
  • Machined boost signal port with installed plug
  • Modern turbine wheel aerodynamics
  • Oil-cooled center housing

Flange diagram

Super Core

Compressor    Turbine
Super Core PN Inducer Exducer Trim A/R Inducer Exducer Trim Rotation Hinta
913840-5001S
Loppu varastosta
58mm 76mm 58 0.72 68mm 62mm 84 Standard
799.00 € 644.35 € alv. 0%
Compressor    Turbine
Super Core PN Inducer Exducer Trim A/R Inducer Exducer Trim Hinta
Turbo PN: 913840-5001S
799.00 € 644.35 € alv. 0%
913840-5001S
Compressor Inducer
58mm 		Exducer
76mm		 Trim
58		 A/R
0.72		 Turbine Inducer
68mm 		Exducer
62mm		 Trim
84
799.00 €
Rotation: Standard Loppu varastosta | 644.35 € alv. 0%

Turbine Hsg

Non Wastegate
Turbine Kit PN A/R Inlet Outlet Wastegate Divided Trim Rotation Hinta
740902-0125
Loppu varastosta
0.95 T4 V-Band No Yes 84 Standard
259.00 € 208.87 € alv. 0%
740902-0123
Loppu varastosta
0.82 T3 V-Band No No 84 Standard
249.00 € 200.81 € alv. 0%
740902-0124
Loppu varastosta
0.82 T4 V-Band No No 84 Standard
249.00 € 200.81 € alv. 0%
Turbine Kit PN A/R Inlet Outlet Wastegate Divided Trim Hinta
Turbine Kit PN: 740902-0125
259.00 € 208.87 € alv. 0%
740902-0125
A/R
0.95		 Inlet
T4		 Outlet
V-Band		 Wastegate
No		 Divided
Yes		 Trim
84
259.00 €
Rotation: Standard Loppu varastosta | 208.87 € alv. 0%
Turbine Kit PN: 740902-0123
249.00 € 200.81 € alv. 0%
740902-0123
A/R
0.82		 Inlet
T3		 Outlet
V-Band		 Wastegate
No		 Divided
No		 Trim
84
249.00 €
Rotation: Standard Loppu varastosta | 200.81 € alv. 0%
Turbine Kit PN: 740902-0124
249.00 € 200.81 € alv. 0%
740902-0124
A/R
0.82		 Inlet
T4		 Outlet
V-Band		 Wastegate
No		 Divided
No		 Trim
84
249.00 €
Rotation: Standard Loppu varastosta | 200.81 € alv. 0%
