GBC17-250

GBC17-250

Horsepower: 150 - 250

Displacement: 0.6L - 1.5L

Features:

  • 36mm compressor inducer
  • 17, 20 and 22 outline interchangeable
  • 150 –350 horsepower capability
  • Integrated wastegate assembly with calibrated actuator
  • Billet compressor wheel with extended tip design for higher pressure ratio capability
  • GTX Gen II compressor aero with modern gasoline turbine wheel aero
  • Supports up to 250 horsepower
  • Forged fully-machined compressor wheel
  • Journal bearing rotating group
  • Internally wastegated turbine housing
  • Engineered for small displacement engines including powersports, personal watercraft and automobiles

Turbocharger

Compressor    Turbine   Turbine kit
Turbo PN Inducer Exducer Trim A/R Inducer Exducer Trim A/R Inlet Outlet Wastegate Divided Rotation Hinta
896052-5003S Turbo GBC17-250 - 896052-5003S
Loppu varastosta
36mm 49mm 55 0.52 44mm 40mm 80 0.50 T25 5-Bolt Yes No Standard
750.00 € 604.84 € alv. 0%
Compressor    Turbine   Turbine kit
Turbo PN Inducer Exducer Trim A/R Inducer Exducer Trim A/R Inlet Outlet Wastegate Divided Hinta
Turbo PN: 896052-5003S
750.00 € 604.84 € alv. 0%
896052-5003S
Compressor    Inducer
36mm
Exducer
49mm
Trim
55
A/R
0.52
Turbine    Inducer
44mm
Exducer
40mm
Trim
80
Turbine kit    A/R
0.50
Inlet
T25
Outlet
5-Bolt
Wastegate
Yes
Divided
No
750.00 €
Rotation: Standard Loppu varastosta | 604.84 € alv. 0%
