G35-900

G35-900

Horsepower: 550 - 900

Displacement: 2.5L - 5.5L

Features:

  • Garrett G Series compressor aerodynamics for maximum HP
  • 62mm turbocharger compressor option
  • New turbine wheel aero constructed of MAR-M alloy rated for up to 1050° C
  • Stainless steel turbine housing options rated up to 1050° C
  • Oil restrictor and water fittings included
  • Fully machined speed sensor and pressure ports

Super Core

Compressor    Turbine
Super Core PN Inducer Exducer Trim A/R Inducer Exducer Trim Rotation Hinta
880695-5001S
Loppu varastosta
62mm 76mm 65 0.72 68mm 62mm 84 Standard
1649.00 € 1329.84 € alv. 0%
Compressor    Turbine
Super Core PN Inducer Exducer Trim A/R Inducer Exducer Trim Hinta
Turbo PN: 880695-5001S
1649.00 € 1329.84 € alv. 0%
880695-5001S
Compressor Inducer
62mm
Exducer
76mm
Trim
65
A/R
0.72
Turbine Inducer
68mm
Exducer
62mm
Trim
84
1649.00 €
Rotation: Standard Loppu varastosta | 1329.84 € alv. 0%

Turbine Hsg

Non Wastegate
Turbine Kit PN A/R Inlet Outlet Wastegate Divided Trim Rotation Hinta
740902-0105
Loppu varastosta
1.21 V-Band V-Band No No 84 Standard
539.00 € 434.68 € alv. 0%
740902-0103
Loppu varastosta
0.83 V-Band V-Band No No 84 Standard
529.00 € 426.61 € alv. 0%
740902-0104
Loppu varastosta
1.01 V-Band V-Band No No 84 Standard
539.00 € 434.68 € alv. 0%
740902-0102
Loppu varastosta
0.61 V-Band V-Band No No 84 Standard
529.00 € 426.61 € alv. 0%
Turbine Kit PN A/R Inlet Outlet Wastegate Divided Trim Hinta
Turbine Kit PN: 740902-0105
539.00 € 434.68 € alv. 0%
740902-0105
A/R
1.21
Inlet
V-Band
Outlet
V-Band
Wastegate
No
Divided
No
Trim
84
539.00 €
Rotation: Standard Loppu varastosta | 434.68 € alv. 0%
Turbine Kit PN: 740902-0103
529.00 € 426.61 € alv. 0%
740902-0103
A/R
0.83
Inlet
V-Band
Outlet
V-Band
Wastegate
No
Divided
No
Trim
84
529.00 €
Rotation: Standard Loppu varastosta | 426.61 € alv. 0%
Turbine Kit PN: 740902-0104
539.00 € 434.68 € alv. 0%
740902-0104
A/R
1.01
Inlet
V-Band
Outlet
V-Band
Wastegate
No
Divided
No
Trim
84
539.00 €
Rotation: Standard Loppu varastosta | 434.68 € alv. 0%
Turbine Kit PN: 740902-0102
529.00 € 426.61 € alv. 0%
740902-0102
A/R
0.61
Inlet
V-Band
Outlet
V-Band
Wastegate
No
Divided
No
Trim
84
529.00 €
Rotation: Standard Loppu varastosta | 426.61 € alv. 0%
