GBC20-300

GBC20-300

Horsepower: 170 - 300

Displacement: 0.8L - 2.0L

Features:

  • 39mm compressor inducer
  • Outline interchangeable with GBC 17 / 22
  • 170-300 horsepower capability
  • Integrated wastegate assembly with calibrated actuator
  • Billet compressor wheel with extended tip design for higher pressure ratio capability
  • GTX Gen II compressor aero with modern gasoline turbine wheel aero
  • Supports up to 300 horsepower
  • Forged Fully-Machined Compressor Wheel
  • Journal Bearing Rotating Group
  • Internally wastegated turbine housing
  • Engineered for small displacement engines including powersports, personal watercraft and automobiles

Turbocharger

Compressor    Turbine   Turbine kit
Turbo PN Inducer Exducer Trim A/R Inducer Exducer Trim A/R Inlet Outlet Wastegated Divided Rotation Price
896053-5003S Turbo GBC20-300 - 896053-5003S
Out of stock
39mm 52mm 57 0.59 47mm 42mm 84 0.55 T25 5-Bolt Yes No Standard
830.00 € 669.35 € VAT 0%
Compressor    Turbine   Turbine kit
Turbo PN Inducer Exducer Trim A/R Inducer Exducer Trim A/R Inlet Outlet Wastegated Divided Price
Turbo PN: 896053-5003S
830.00 € 669.35 € VAT 0%
896053-5003S
Compressor    Inducer
39mm
Exducer
52mm
Trim
57
A/R
0.59
Turbine    Inducer
47mm
Exducer
42mm
Trim
84
Turbine kit    A/R
0.55
Inlet
T25
Outlet
5-Bolt
Wastegated
Yes
Divided
No
830.00 €
Rotation: Standard Out of stock | 669.35 € VAT 0%
