GTW3884R

GTW3884R

Horsepower: 450 - 950

Displacement: 2.0L - 6.0L

Features:

  • Ported shroud design for surge resistance
  • Available in both journal bearing and ball bearing options
  • Forged fully-machined billet compressor wheel
  • Inconel Super-alloy turbine wheel
  • Lightweight aluminium backplate

*841279 Journal Bearing Option

*841691 Ball Bearing Option

Turbocharger includes FREE gasket kit

Super Core Reference Data  Compressor    Turbine
Super Core PN CHRA Inducer Exducer Trim A/R Inducer Exducer Trim
841297-5003S 715582-0008 62mm 84mm 54 0,70 74mm 65mm 76
841297-5004S 715582-0009 64mm 84mm 58 0,70 74mm 65mm 76
841297-5005S 715582-0010 67mm 84mm 64 0,70 74mm 65mm 76
841691-5003S 757197-0012 62mm 84mm 54 0,70 74mm 65mm 76
841691-5004S 757197-0013 64mm 84mm 58 0,70 74mm 65mm 76
841691-5005S 757197-0014 67mm 84mm 64 0,70 74mm 65mm 76
Notes:Super Core and Turbine Kit Sold Separately     Turbine Kit PN A/R Inlet Outlet Wastegate Divided Trim
844669-0009 0,96 T4 V-Band Free Float N 76
844669-0010 1,14 T4 V-Band Free Float N 76

Super Core

Compressor    Turbine
Super Core PN Inducer Exducer Trim A/R Inducer Exducer Trim Rotation Price
841691-5005S
Out of stock
67mm 84mm 64 0.70 74mm 65mm 76 Standard
1099.00 € 886.29 € VAT 0%
841691-5004S
Out of stock
64mm 84mm 58 0.70 74mm 65mm 76 Standard
989.00 € 797.58 € VAT 0%
841691-5003S
Out of stock
62mm 84mm 54 0.70 74mm 65mm 76 Standard
989.00 € 797.58 € VAT 0%
841297-5005S
Out of stock
67mm 84mm 64 0.70 74mm 65mm 76 Standard
699.00 € 563.71 € VAT 0%
841297-5004S
Out of stock
64mm 84mm 58 0.70 74mm 65mm 76 Standard
649.00 € 523.39 € VAT 0%
841297-5003S
Out of stock
62mm 84mm 54 0.70 74mm 65mm 76 Standard
649.00 € 523.39 € VAT 0%
Compressor    Turbine
Super Core PN Inducer Exducer Trim A/R Inducer Exducer Trim Price
Turbo PN: 841691-5005S
1099.00 € 886.29 € VAT 0%
841691-5005S
Compressor Inducer
67mm
Exducer
84mm
Trim
64
A/R
0.70
Turbine Inducer
74mm
Exducer
65mm
Trim
76
1099.00 €
Rotation: Standard Out of stock | 886.29 € VAT 0%
Turbo PN: 841691-5004S
989.00 € 797.58 € VAT 0%
841691-5004S
Compressor Inducer
64mm
Exducer
84mm
Trim
58
A/R
0.70
Turbine Inducer
74mm
Exducer
65mm
Trim
76
989.00 €
Rotation: Standard Out of stock | 797.58 € VAT 0%
Turbo PN: 841691-5003S
989.00 € 797.58 € VAT 0%
841691-5003S
Compressor Inducer
62mm
Exducer
84mm
Trim
54
A/R
0.70
Turbine Inducer
74mm
Exducer
65mm
Trim
76
989.00 €
Rotation: Standard Out of stock | 797.58 € VAT 0%
Turbo PN: 841297-5005S
699.00 € 563.71 € VAT 0%
841297-5005S
Compressor Inducer
67mm
Exducer
84mm
Trim
64
A/R
0.70
Turbine Inducer
74mm
Exducer
65mm
Trim
76
699.00 €
Rotation: Standard Out of stock | 563.71 € VAT 0%
Turbo PN: 841297-5004S
649.00 € 523.39 € VAT 0%
841297-5004S
Compressor Inducer
64mm
Exducer
84mm
Trim
58
A/R
0.70
Turbine Inducer
74mm
Exducer
65mm
Trim
76
649.00 €
Rotation: Standard Out of stock | 523.39 € VAT 0%
Turbo PN: 841297-5003S
649.00 € 523.39 € VAT 0%
841297-5003S
Compressor Inducer
62mm
Exducer
84mm
Trim
54
A/R
0.70
Turbine Inducer
74mm
Exducer
65mm
Trim
76
649.00 €
Rotation: Standard Out of stock | 523.39 € VAT 0%

Turbine Housing

Non Wastegated
Turbine Kit PN A/R Inlet Outlet Wastegated Divided Trim Rotation Price
844669-0010
Out of stock
1.14 T4 V-Band No No 76 Standard
319.00 € 257.26 € VAT 0%
844669-0009
Out of stock
0.96 T4 V-Band No No 76 Standard
319.00 € 257.26 € VAT 0%
Turbine Kit PN A/R Inlet Outlet Wastegated Divided Trim Price
Turbine Kit PN: 844669-0010
319.00 € 257.26 € VAT 0%
844669-0010
A/R
1.14
Inlet
T4
Outlet
V-Band
Wastegated
No
Divided
No
Trim
76
319.00 €
Rotation: Standard Out of stock | 257.26 € VAT 0%
Turbine Kit PN: 844669-0009
319.00 € 257.26 € VAT 0%
844669-0009
A/R
0.96
Inlet
T4
Outlet
V-Band
Wastegated
No
Divided
No
Trim
76
319.00 €
Rotation: Standard Out of stock | 257.26 € VAT 0%
