G40-1150

G40-1150

Horsepower: 500 - 1150

Displacement: 2.0L - 6.0L

Features:

  • G-Series compressor aero increases flow up to 35% (compared to GTX4088R)
  • Dual ceramic ball bearing with steel cages
  • G-Series turbine aero increases flow 16% (compared to GTX4088R)
  • Inconel turbine wheel with 77mm inducer flows up to 43 lbs/min
  • Lighweight aluminium backplate
  • Fully machined speed sensor and pressure ports
  • Water fittings included with super core
  • Stainless steel turbine housings available with T4 twinn scroll inlet
  • T4 turbine housing outlet V-Band dimension is equal to existing GTX42, GTX45 and G42 models

Super Core

Compressor    Turbine
Super Core PN Inducer Exducer Trim A/R Inducer Exducer Trim Rotation Price
860777-5002S
Out of stock
71mm 88mm 65 0.80 77mm 70mm 84 Standard
1789.00 € 1442.74 € VAT 0%
Compressor    Turbine
Super Core PN Inducer Exducer Trim A/R Inducer Exducer Trim Price
Turbo PN: 860777-5002S
1789.00 € 1442.74 € VAT 0%
860777-5002S
Compressor Inducer
71mm
Exducer
88mm
Trim
65
A/R
0.80
Turbine Inducer
77mm
Exducer
70mm
Trim
84
1789.00 €
Rotation: Standard Out of stock | 1442.74 € VAT 0%

Turbine Housing

Non Wastegated
Turbine Kit PN A/R Inlet Outlet Wastegated Divided Trim Rotation Price
757707-0027
Out of stock
0.85 V-Band V-Band No No 84 Standard
569.00 € 458.87 € VAT 0%
757707-0029
Out of stock
1.06 V-Band V-Band No No 84 Standard
569.00 € 458.87 € VAT 0%
757707-0033
Out of stock
0.95 T4 V-Band No Yes 84 Standard
609.00 € 491.13 € VAT 0%
757707-0028
Out of stock
0.95 V-Band V-Band No No 84 Standard
569.00 € 458.87 € VAT 0%
757707-0032
Out of stock
0.85 T4 V-Band No Yes 84 Standard
689.00 € 555.65 € VAT 0%
757707-0035
Out of stock
1.19 T4 V-Band No Yes 84 Standard
609.00 € 491.13 € VAT 0%
757707-0034
Out of stock
1.06 T4 V-Band No Yes 84 Standard
609.00 € 491.13 € VAT 0%
757707-0030
Out of stock
1.19 V-Band V-Band No No 84 Standard
569.00 € 458.87 € VAT 0%
Turbine Kit PN A/R Inlet Outlet Wastegated Divided Trim Price
Turbine Kit PN: 757707-0027
569.00 € 458.87 € VAT 0%
757707-0027
A/R
0.85
Inlet
V-Band
Outlet
V-Band
Wastegated
No
Divided
No
Trim
84
569.00 €
Rotation: Standard Out of stock | 458.87 € VAT 0%
Turbine Kit PN: 757707-0029
569.00 € 458.87 € VAT 0%
757707-0029
A/R
1.06
Inlet
V-Band
Outlet
V-Band
Wastegated
No
Divided
No
Trim
84
569.00 €
Rotation: Standard Out of stock | 458.87 € VAT 0%
Turbine Kit PN: 757707-0033
609.00 € 491.13 € VAT 0%
757707-0033
A/R
0.95
Inlet
T4
Outlet
V-Band
Wastegated
No
Divided
Yes
Trim
84
609.00 €
Rotation: Standard Out of stock | 491.13 € VAT 0%
Turbine Kit PN: 757707-0028
569.00 € 458.87 € VAT 0%
757707-0028
A/R
0.95
Inlet
V-Band
Outlet
V-Band
Wastegated
No
Divided
No
Trim
84
569.00 €
Rotation: Standard Out of stock | 458.87 € VAT 0%
Turbine Kit PN: 757707-0032
689.00 € 555.65 € VAT 0%
757707-0032
A/R
0.85
Inlet
T4
Outlet
V-Band
Wastegated
No
Divided
Yes
Trim
84
689.00 €
Rotation: Standard Out of stock | 555.65 € VAT 0%
Turbine Kit PN: 757707-0035
609.00 € 491.13 € VAT 0%
757707-0035
A/R
1.19
Inlet
T4
Outlet
V-Band
Wastegated
No
Divided
Yes
Trim
84
609.00 €
Rotation: Standard Out of stock | 491.13 € VAT 0%
Turbine Kit PN: 757707-0034
609.00 € 491.13 € VAT 0%
757707-0034
A/R
1.06
Inlet
T4
Outlet
V-Band
Wastegated
No
Divided
Yes
Trim
84
609.00 €
Rotation: Standard Out of stock | 491.13 € VAT 0%
Turbine Kit PN: 757707-0030
569.00 € 458.87 € VAT 0%
757707-0030
A/R
1.19
Inlet
V-Band
Outlet
V-Band
Wastegated
No
Divided
No
Trim
84
569.00 €
Rotation: Standard Out of stock | 458.87 € VAT 0%
