G30-770

G30-770

Horsepower: 475 - 770

Displacement: 2.0L - 3.5L

Features:

  • Garrett G Series compressor aerodynamics for maximum HP
  • New turbine wheel aero contructed of MAR-M alloy rated for up to 1050° C
  • Stainless steel turbine housing options rated for up to 1050° C
  • Oil restrictor and water fittings included
  • Fully machined speed senson and pressure ports

Turbocharger

Compressor    Turbine   Turbine kit
Turbo PN Inducer Exducer Trim A/R Inducer Exducer Trim A/R Inlet Outlet Wastegated Divided Rotation Price
880704-5005S Turbo G30-770 - 880704-5005S
Out of stock
58mm 71mm 65 0.72 60mm 55mm 84 0.83 V-Band V-Band Yes No Standard
2139.00 € 1725.00 € VAT 0%
880704-5006S Turbo G30-770 - 880704-5006S
Out of stock
58mm 71mm 65 0.72 60mm 55mm 84 1.01 V-Band V-Band Yes No Standard
2139.00 € 1725.00 € VAT 0%
880697-5008S Turbo G30-770 - 880697-5008S
Out of stock
58mm 71mm 65 0.72 60mm 55mm 84 0.61 V-Band V-Band No No Standard
1949.00 € 1571.77 € VAT 0%
880697-5009S Turbo G30-770 - 880697-5009S
Out of stock
58mm 71mm 65 0.72 60mm 55mm 84 0.83 V-Band V-Band No No Standard
1949.00 € 1571.77 € VAT 0%
880697-5010S Turbo G30-770 - 880697-5010S
Out of stock
58mm 71mm 65 0.72 60mm 55mm 84 1.01 V-Band V-Band No No Standard
1949.00 € 1571.77 € VAT 0%
Compressor    Turbine   Turbine kit
Turbo PN Inducer Exducer Trim A/R Inducer Exducer Trim A/R Inlet Outlet Wastegated Divided Price
Turbo PN: 880704-5005S
2139.00 € 1725.00 € VAT 0%
880704-5005S
Compressor    Inducer
58mm
Exducer
71mm
Trim
65
A/R
0.72
Turbine    Inducer
60mm
Exducer
55mm
Trim
84
Turbine kit    A/R
0.83
Inlet
V-Band
Outlet
V-Band
Wastegated
Yes
Divided
No
2139.00 €
Rotation: Standard Out of stock | 1725.00 € VAT 0%
Turbo PN: 880704-5006S
2139.00 € 1725.00 € VAT 0%
880704-5006S
Compressor    Inducer
58mm
Exducer
71mm
Trim
65
A/R
0.72
Turbine    Inducer
60mm
Exducer
55mm
Trim
84
Turbine kit    A/R
1.01
Inlet
V-Band
Outlet
V-Band
Wastegated
Yes
Divided
No
2139.00 €
Rotation: Standard Out of stock | 1725.00 € VAT 0%
Turbo PN: 880697-5008S
1949.00 € 1571.77 € VAT 0%
880697-5008S
Compressor    Inducer
58mm
Exducer
71mm
Trim
65
A/R
0.72
Turbine    Inducer
60mm
Exducer
55mm
Trim
84
Turbine kit    A/R
0.61
Inlet
V-Band
Outlet
V-Band
Wastegated
No
Divided
No
1949.00 €
Rotation: Standard Out of stock | 1571.77 € VAT 0%
Turbo PN: 880697-5009S
1949.00 € 1571.77 € VAT 0%
880697-5009S
Compressor    Inducer
58mm
Exducer
71mm
Trim
65
A/R
0.72
Turbine    Inducer
60mm
Exducer
55mm
Trim
84
Turbine kit    A/R
0.83
Inlet
V-Band
Outlet
V-Band
Wastegated
No
Divided
No
1949.00 €
Rotation: Standard Out of stock | 1571.77 € VAT 0%
Turbo PN: 880697-5010S
1949.00 € 1571.77 € VAT 0%
880697-5010S
Compressor    Inducer
58mm
Exducer
71mm
Trim
65
A/R
0.72
Turbine    Inducer
60mm
Exducer
55mm
Trim
84
Turbine kit    A/R
1.01
Inlet
V-Band
Outlet
V-Band
Wastegated
No
Divided
No
1949.00 €
Rotation: Standard Out of stock | 1571.77 € VAT 0%
